* Finishes and layout are for illustrative purposes only
Our single-slope models combine simplicity, elegance, and functionality. By giving you the freedom to choose the direction of the roof pitch for smooth, worry-free water drainage, these models adapt perfectly to all your projects—whether residential, rental, or recreational.
Its ingeniously engineered structure, built with high-performance OSBLOCK™ blocks, allows for fast, hassle-free installation, giving you complete freedom to customize both the interior and exterior to suit your taste. Add warmth, style, and personality to create a unique space that truly reflects you.
Our design stands apart from traditional construction. With OSBLOCK™ blocks, you achieve effective R-32 insulation and superior soundproofing—elevating your vision to a truly high-end project.
Available starting at $30,995 plus applicable taxes, this model offers an affordable yet refined solution. Choose even more space by expanding it in 2-foot increments—flexibility guaranteed!
Indicative Pricing — “Garage” Kits
Here is a quick reference grid based on the most popular sizes.
| Dimensions (ft) | Garage on Slab |
|---|---|
| 20×20 | $30,995 |
| 20×22 | $32,490 |
| 20×24 | $33,985 |
| 20×26 | $35,480 |
| 20×28 | $36,975 |
| 20×30 | $38,470 |
| 20×32 | $39,965 |
| 20×34 | $41,460 |
| 20×36 | $42,955 |
| 20×38 | $44,450 |
| 20×40 | $45,945 |
| 20×42 | $47,440 |
| 20×44 | $48,935 |
| 20×46 | $50,430 |
| 20×48 | $51,925 |
| 20×50 | $53,420 |
| 20×52 | $54,915 |
| 20×54 | $56,410 |
| 20×56 | $57,905 |
| 20×58 | $59,400 |
| 20×60 | $60,895 |
| Dimensions (ft) | Garage on Slab |
|---|---|
| 24×24 | $36,995 |
| 24×26 | $38,654 |
| 24×28 | $40,313 |
| 24×30 | $41,972 |
| 24×32 | $43,631 |
| 24×34 | $45,290 |
| 24×36 | $46,949 |
| 24×38 | $48,608 |
| 24×40 | $50,267 |
| 24×42 | $51,926 |
| 24×44 | $53,585 |
| 24×46 | $55,244 |
| 24×48 | $56,903 |
| 24×50 | $58,562 |
| 24×52 | $60,221 |
| 24×54 | $61,880 |
| 24×56 | $63,539 |
| 24×58 | $65,198 |
| 24×60 | $66,857 |
| Dimensions (ft) | Garage on Slab |
|---|---|
| 28×28 | $41,995 |
| 28×30 | $43,770 |
| 28×32 | $45,545 |
| 28×34 | $47,320 |
| 28×36 | $49,095 |
| 28×38 | $50,870 |
| 28×40 | $52,645 |
| 28×42 | $54,420 |
| 28×44 | $56,195 |
| 28×46 | $57,970 |
| 28×48 | $59,745 |
| 28×50 | $61,520 |
| 28×52 | $63,295 |
| 28×54 | $65,070 |
| 28×56 | $66,845 |
| 28×58 | $68,620 |
| 28×60 | $70,395 |
List of Inclusions – Construction Kit
This list outlines the components included in your prefabricated construction kit. Some modifications are available at an additional cost.
🗂️ Construction Plans
Complete base plans compliant for permit applications Modifications available at additional cost
🧱 Floor
* Items not included with the following options: concrete slab or garage.
*16″ I-joist floor system *Rim joist *Perimeter curb *3/4″ tongue-and-groove OSB sheathing Ready to receive the flooring finish of your choice
🏗️ Wall – R32 Effective Insulation
OSBLOCK™ wall kit including: – Starter/finishing plate – Exterior corner – OSBLOCK™ patented locking mechanism – Locking key – Carrying handle For more details: https://www.osblock.ca/ressources-en-ligne/ Headers Exterior air barrier 1×3 exterior strapping Interior pre-strapped as part of OSBLOCK™ wall *No vapor barrier required* Ready to receive the exterior and interior finish of your choice
🏠 Roof
16″ I-joist roof system 5/8″ tongue-and-groove OSB Peel-and-stick membrane (eaves protection) Eaves/Cornice Starter flashing (aluminum) 25-year asphalt shingles Vented ridge attic ventilation **Possibility to upgrade shingles to metal roofing for an additional cost**
🧊 Ceiling – R44.5 Effective Insulation
R40 batt insulation ½” rigid insulation panels R4.5 (Enermax or equivalent) 1×3 strapping Ready to receive the ceiling finish of your choice
🚪 Doors and Windows
Allowance included for the purchase of doors and windows of your choice: – 20×20 1-storey: $8,000 -Garage: $6,000 – 20×20 2-storey: $12,000 – 24×24 1-storey: $10,000 – 24×24 2-storey: $15,000 – 28×28 1-storey: $10,000 – 28×28 2-storey: $15,000
❌ Exclusions
Basic hardware: screws, nails, membranes, tapes, urethane, etc. Transportation from factory to project site **Note: Hardware is included if you choose the installation option.**
Basic hardware:
- Screws, nails, membranes, tapes, sealants, etc.
Plan modifications (fees apply)
Transportation from the factory to the project site (fees apply)
